Stainless Steel Tanks

Used 4800 gallon 304 stainless steel tank. Manufactured by Alloy Fab. ATM @140F. Cone top, flat bottom. 5600lb. Serial #1-165A. Built 1991. Past use Toluene filtrite tank.

Used 4800 gallon 304 stainless steel tank. Manufactured by Alloy Fab. ATM @140F. Cone top, flat bottom. 5600lb. Serial #1-166A. Built 1991.

Used 4800 gallon 304 stainless steel tank. Manufactured by Alloy Fab. ATM @140F. Cone top, flat bottom. 5600lb. Serial #1-167A. Built 1991.

Used 4750 Gallon, 304 Stainless Steel, Vertical Tank. 84" Diameter x 200" straight side, flat top, sloped bottom. Internal sidewall ladder. Openings top 1-1/2" tri-clamp, (2) 2" NPT, 3-1/2" threaded, 20" man way with cover. 2-1/2" Off center bottom outlet. Mounted on 4 carbon steel legs with skirt. No manufacturers tag. Previous use: water storage for brewery.

Used 4600 gallon 304 Stainless steel jacketed mix tank. Manufactured by Alloy Fab. Internal ATM@335F. Jacket rated 44psi @335F. 7.5 HP dual hub agitator. (3) Sidewall baffles. Dished heads. 9'6 Dia x 7'6"T/T. 8730 Lb. Serial #1-146A. Built 1991. Past use Crystallizer vessel.

Used 4500 gallon stainless stell mix tank. 7'6"ID x 14' Straight-side (OAH 18'). Flat top, slight cone bottom with 2” diameter center bottom discharge. Top head includes MixMor Model T0B-2-N20 bridge mounted, top entering agitator drive and a partial hinged lid. Agitation includes a stainless steel shaft and two 4-blade pitched turbine bolted paddles, driven by 2 HP, 208-230/460V, 1725 RPM, 3/60Hz motor thru Falk gear reducer. (4) Leg mounted.

Used vertical 304 Stainless Steel 4000 Gal Tank with agitator, mfg by Reco, 1967. Cone top, Flat bottom. 8' dia x 10'6" Straight side. 3/16" Thickness. Bottom head support. 5 HP Agitator. Top Nozzles: (2)1.5", (4)4", 6", 10"; Shell 20" Manway, (3)1.5", 3". Previous use: Glycol Extraction Tank.

Used 4000 gallon 316L Stainless Steel Tank. Manufactured by K&E Fabricating. 72"Dia x 204" Straight-side. Dome top, dish bottom. Leg mounted. Built 2014.

Used 4000 gallon 316L Stainless Steel Tank. Manufactured by K&E Fabricating. 72"Dia x 204" Straight-side. Dome top, dish bottom. Leg mounted. Built 2014.

Used 4000 gallon Stainless Steel mix tank. Manufactured by CE Howard. Style 12448 B. 7'D x 13 Straight side (18'3" OAH) with flat top and cone bottom. 3.5" Center bottom discharge with threaded connection to 90-degree elbow pipe. Top head includes MixMor Model T0-1.5 bridge-mounted, top-entering agitator drive, two 3” diameter openings, and partial hinged lid. Agitation includes stainless steel shaft and two 4-blade pitched turbine bolted paddles driven by 2 HP motor. Stand mounted. Serial #9754-1.

Used 3900 gallon 304 Stainless Steel Vertical Mix tank with internal coil. 304SS coil, insulated. Shell rated ATM @475F. Top Mounted Agitation, (4) Internal Sidewall Baffles, Flat Flanged Top & Dished Bottom.

Used 3900 gallon 304 stainless steel tank. Manufactured by Alloy Fab. Cone Top, flat bottom. 4600Lb. Serial #1-164A. Built 1991.

Used vertical 304 Stainless Steel 3645 Gal Tank with agitator, Mfg by Missouri Boiler, 1968. Dished heads. 8' dia x 8'4" straight side. Has Agitator shaft and propeller (Missing Motor)Previous use: Pre Wash feed Tank.

Used 3500 gallon 304 Stainless steel tank. Manufactured by Alloy Fabricators. ATM@140F. Cone top, flat bottom. 4140 lb. 8'dia x 9'T/T. Serial #1-168A. Built 1991

Unused 3170 gallon 304 Stainless Steel double walled storage tank. Manufactured by Southern Tank. Carbon Steel outer wall. Slight Cone top, flat bottom. Code UL-142. Serial #C18493862.

Unused 3170 gallon 304 Stainless Steel double walled storage tank. Manufactured by Southern Tank. Carbon Steel outer wall. Slight Cone top, flat bottom. Code UL-142. 15'H x 6'D.

Unused 3170 gallon 304 Stainless Steel double walled storage tank. Manufactured by Southern Tank. Carbon Steel outer wall. Slight Cone top, flat bottom. Code UL-142. 15'H x 6'D. Serial #C18493867

Unused 3170 gallon 304 Stainless Steel double walled storage tank. Manufactured by Southern Tank. Carbon Steel outer wall. Slight Cone top, flat bottom. Code UL-142.

Used 3000 Gallon 304 Stainless Steel Tank. Manufactured by Hicks Equipment. 6' diameter x 10' straight side with 3' cone. Cone Bottom with 8" diameter center bottom discharge. 10" and 12" diameter cross feed/transfer/overflow pipes with pneumatic/manual slide gate valves control. Flow control transmitter, temp probe, mounted on steel legs. Serial #4-8352-1. Built 1999. Previously used as pulper/finisher feed tank in food processing facility.

Used 2750 gallon stainless Steel tank. 7'6"ID x 8'Straight-side (OAH 10'4"). Flat top with (2) Partial hinged lids and Cone bottom with 2" Center Bottom outlet. 2HP side entering agitator. (4) Leg mounted.

Used approximately 2500 gallon vertical 304 stainless steel tank. Approximately 84" diameter X 9' 4" straight side. Open top. Flat bottom. Center bottom outlet.

Used fully reconditioned 2,500 gallon 316L stainless steel processing tank with dome top, cone bottom and pressure wall. Mfg DCI. 316L interior, top manway, offset vertical agitator, double spray wall, 2" outlet, stainless steel legs with adjustable feet, 23 Sq Ft jacketed on lower side wall only. Approximately 88" Dia X 183" H. Serial # D-53937.

Used 2250 gallon Stainless Steel Mix tank. 6’ID x 8’3” straight side (16'OAH). Dish top and dish bottom. 15” diameter flange connection to 2” diameter pipe discharge. Top-entering, flange-mounted agitation with stainless steel shaft and two 3-blade stainless steel props, driven by 3 HP, 208-220/440V, 1760 RPM, 3/60Hz motor. 18” diameter top-entering manway with six top inlets two 4”, two 2” & two 1 1/2”. Lug Mounted within mild steel frame with (4) legs and footpads.

Used 2200 gallon stainless Steel tank. Manufactured by JVNW (ICC). Serial #12908. slight cone bottom. 7.9 ft. Dia. x 6.1 ft tall. (6) Leg mounted. Past Use: Whirlpool tank in a brewery

Used 2100 gallon Stainless Steel tank. Manufactured by Commerical Sheet Metal Works. 6'D x 10' Straight side (11'4" OAH). Sloped bottom with side outle. 18" Top manway and (2) 2" side bottom outlets. (6) Leg with footpad mounted.

Used 2000 Gallon Stainless Steel Agitated Tank. 6’4” diameter x 8’ straight side (10"9' OAH) with a slight cone top and slight cone bottom, 2 1/2” diameter center bottom discharge with a 90-degree elbow. Side-entering agitator connected to flange connection. Agitator driven by 2 HP motor. Top head includes 18” diameter manway and two 2-1/2” diameter openings. Straight side includes side ladder with step platform. (5) Leg mounted.

Used 2000 gallon Stainless Steel agitated tank. 6'D x 10' Straight side (12' OAH). Cone top, sloped bottom with 2" side discharge with manual valve and sample port with valve. 2HP Side entering agitator. 18" Top manway and (2) 2" openings. (6) Leg mounted.

Used 1500 gallon Walker Stainless Steel Tank. Made in 1985. Serial #VHT4006SS.

Unused 1200 gallon vertical 304 Stainless Steel quench tank. Manufactured by Bendel. Internal rated ATMOS @ -20 to 600 F. Welded dished heads. 4'D X 12'H straight side. Top Fittings: 12" "U" vent. 3" center bottom drain. (1) 4" side top inlet, (1) 6" side bottom outlet, (1) 12" side bottom inlet connected to downspout sparge tube. (1) 2" side bottom inlet for level switch, (1) 2" offset bottom outlet for temperature transmitter, and (1) 30" side bottom manway. (8) center baffle clips, (2) center baffles, (2) outer baffles .Shell and Head thickness 0.25". Mounted on (4) angle iron legs giving 23" clearance from bottom outlet to floor. Insulated and covered with aluminum sheathing. Serial #14716-1/1. Built 2015. Weight 4500#

Used 1200 gallon vertical stainless steel vessel. 304 stainless steel. Dished heads. On leg supports.

Used 4000 liter Stainless Steel tank. Manufactured by Lee Industries. Model 4000LDB. Dome top, dish bottom. Top manway. (4) leg mounted. Serial# 67358-8. Built 2011

Used Stainless steel jacketed tank, 1,000 gallon capacity, manufactured by DCI, serial number 87-D-35635. Three zone dimple jacket covered by insulation. Tank measures 90" diameter X 40" straight side with cone bottom. Includes 20" top manway. Complete with heavy-duty scrape agitator driven by 2 HP, 230/460 V, 1750 rpm Baldor motor through SEW Eurodrive. 2" center bottom outlet with tri-clamp fitting. Mounted on four (4) stainless steel pipe legs. Includes side-mounted ladder. Previously used in an Research & Development facility. (NOTE: Jacket leaks)

USED 1000 GAL 304L-SS JACKETED MIXING TANK, MFG. BY FABRICON IN 2003. DISHED TOP & BOTTOM. 4'8" DIA X 2'1" STRAIGHT SIDE. INTERNAL RATED ATM @ 300 DEG F. JACKET RATED 150 PSI @ 300 DEG F. (5) TURNS OF 304SS 2" HALF PIPE COIL JACKET ON SHELL TANGENT TO TANGENT AND DIMPLE TYPE JACKET ON BOTTOM HEAD. 316-SS PHILADELPHIA AGITATOR MODEL #PTM-4040. 7.5 HP, 17.1 GEAR RATIO; 100 RPM OUTPUT SPEE, 1800/100 RPM. NOZZLES: TOP (4)2", (4)3", 6", 8" AGITATOR, 18" MUELLER MANWAY; SIDES (3)2"; BOTTOM (2)2"; 2" WITH ACTUATED BALL VALVE. (2) TOP MOUNTED LIFTING LUGS. (4) LEG SUPPORTS. (4) INTERNAL SIDEWALL BAFFLES; EXTERNAL STAINLESS STEEL INSULATION SHEATHING ON SHELL O.D. AND BOTTOM HEAD

Feldmeier 1,000 Gal. S/S High Shear Mix Tank, S/N E-1020-00, with Dome Top/Cone Bottom, with S/S Man Ladder, with Vertical S/S High Shear Agitator, with Top Mounted 40 hp Agitation Motor, 1800 RPM, Internal Tank Dims.: Aprox. 70" Tall x 64" Dia., with Dual CIP Spray Balls, with Top Infeed Ports, with S/S Covers, with Frame Mounted on Load Cells with Fairbanks Digitial Read Out

Used 1000 Gallon Jacketed Stainless Mix Tank. Manufactured by Cherry Burrell. Top mount agitator driven by a 1.6/3 HP, 860/1740 rpm 460 volt motor into gearbox with 42.93 ratio for 20/40 RPM output speed. Jacket Rated 100 PSI @ 300F. CIP Ball. National Board # 3010. Serial #E-130-88. Built 1988. 6' ID x 6' T/T. 3" Side bottom outlet. 9'6" OAH. Last used in sanitary food plant.

Used 1000 gallon stainless steel mix tank. Manufactured by Feldmeier. Dome top, cone bottom. Top mounted agitator with bridge. (4) leg mounted. Safety ladder. Depth gauge. Serial # E-357-03.
