Micronizers & Micronizer Mills

Unused Hosokawa 1500/3 AFG Fluidized Bed Opposed Jet Mill with 10,000CFM Ingersoll Rand Compressor. Includes Spherical Disk Valve, Feed Hopper (60 CU.FT. Working Volume), Baghouse Model JA-289-M12T, Fan For 1500-3 AFG System, 730 L-17, CW, ARR.8 Discharge Fan Assy, Inlet Filter/ Silencer, GEMCO Feed Valve, GEMCO 20"T VLV.CS, FAB.ANSI DR, ROVALVE 20" Knife Gate, 18" Actuated Butterfly Valve, 10"Double Flap Valve Assembly, Butterfly Valves 10" Double Flap Valve Assembly, A-B 1336 PLUS 11 Variable Frequency Drive, Operator Terminal, A-B PLC 500 System, Tank Weigh Module - Load Cell, Weighing Indicator, Air Manifold Assembly, 6"Pressure Control Valve, Pressure Indicating Transmitter, 6" Butterfly Valve, Rosemount Temperature Indicator with RTD, Rosemount Differential Pressure Transmitter, Endress + Hauser Level Element, ABB Drive Motor Rating 6.6v - 1800kw, Delvac Bag Collector, PO Pump 30/12/6, PO Pump 50/12/8, 1.7 Cub Metre Sq Surge Hopper, 6.0 Cub Metre Sq Surge Bin C/Bugemann. Built 2002. Designed for an Ash Benefication Plant.

Used Crown Iron Works, Model 48, Milling Flash Drying System. Major components include: 48"dia Ring Flash Dryer (MFD-105) manufactured by Crown Iron Works, 30000 SCFH @30psig gas train, Forced Draft Blower (F-102A and F-102B), 6670 cfm combustion blower, Burner and Burner Housing, 600 HP DFC exhaust fan, 66400 ACFM capacity Camcorp baghouse, 93" Crown Iron Works Cyclone Assembly (2 units), 60 HP Scott Equipment Back Mixer, 12" dia Anderson Crane Co Inclined Screw feeder and mixing conveyor. Previous use: food-grade orange pulp, 17,000 Lbs/Hr. Built 2013, shutdown 2019.

Used Hosokawa Mill and Dust Collector.

Used APTM Superjet Micronizer Jet Mill. Model SM1-C3. Advanced Powder and Micronisation. Serial #9120.
