PVSA Oxygen Plant - 55 TPD
Other Views - click image for larger view
PVSA Oxygen Plant - 55 TPD PVSA Oxygen Plant - 55 TPD PVSA Oxygen Plant - 55 TPD PVSA Oxygen Plant - 55 TPD PVSA Oxygen Plant - 55 TPD PVSA Oxygen Plant - 55 TPD PVSA Oxygen Plant - 55 TPD
Stock # 532
Capacity 55 TPD
Products Oxygen
Sold

Overview

Used PVSA (Pressure Vacuum Swing Adsorption) oxygen plant designed and supplied by Sumitomo Seika of Japan is now for sale immediately available. Plant commissioned in 2017. Capacity 55 TPD (1,612 Nm3/hour). Product purity 93%, pressure 23.2 PSI (0.16 MPa(G)), temperature 40 - 45 degree C, dew point -60 degree C at 1 atm. Power consumption: 0.4 KWh/Nm3 of 93% O2 at 23.2 PSI. Total installed power 1,070 KW. All the equipment is in excellent condition. The plant has spare parts in stock for two years of operation. OEM support also available.

Major Equipment

Air Filter
Air Blower
Adsorption Tower
Vacuum Pump
Oxygen Compressor
Share
Download Plant Brochure |
SPECIFICATIONS RESOURCES
Year Built
2017
Year Shut
2019
Capacity
55 TPD

For additional information, visit the Resource Center
