3000 Gal GEA Stainless Steel Reactor
Other Views - click image for larger view
3000 Gal GEA Stainless Steel Reactor 3000 Gal GEA Stainless Steel Reactor 3000 Gal GEA Stainless Steel Reactor 3000 Gal GEA Stainless Steel Reactor 3000 Gal GEA Stainless Steel Reactor 3000 Gal GEA Stainless Steel Reactor

3000 gal gea stainless steel reactor

Stock # 21131
Capacity 3000 Gal

Overview

Unused 3000 Gallon (11.5 m3) 304L Stainless Steel Double Wall Crystallizer. Manufactured by GEA. Jacketed. Internal rated -2.90/43 psi ( -.2/3 BARG) @-13F/203F (@-25C/95C), jacket rated -7.25/43psi (-.5/3 BARG) @-13F/203F (@-25C/95C). 18.5kW motor with top mounted side scraper agitation. 84" dia x 20' tall. NB #1263, Serial #091212096D.Weight 13000 lbs. Built 2013. Previous use: Crystallizer Stage 1 in GEA freeze concentration plant.

Share
SPECIFICATIONS TERMS & CONDITIONS
Manufacturer
GEA
Model
NA
Material
304 Stainless Steel
Capacity
3000 Gal
Category
