Used Shell and Tube Heat Exchangers for Sale

Used 1,554 sq.ft. vertical reflux condenser. Mfg by Rubicon Industries. Model #VT221B1-216V. 26" dia x 216" long carbon steel shell rated 150 psi @ 200 Deg F (577) 3/4" x 168" x 18BWG 304L stainless steel tubes rated 200PSI/FV @ 200 deg F. National Board #2105. Serial #3479-2. Built 2008. Weight 5,806 lbs.

Used 1248 Sq Ft Stainless Steel Horizontal Heat Exchanger. 316-SS Shell rated 75/FV PSI @ 350 deg F, 316-SS Tubes rated 14 PSI/FV @ 300 deg F. 316-SS Clad Heads. 3' Shell dia. x 27' L. (145) 1.5" dia Tube Holes, 24'L. Shell Nozzles: 3", 2". Tube Nozzles: 20", 2". With steam chest, Lugs, Rings are CS. Built by Tolan, 1979. NB Stamped

Unused 1185.1 Sq Ft 304L SS Shell and Tube Heat Exchanger. Mfg Praj Industries. 304L SS Shell MAWP 25 PSI@293F. (460) 304 SS Tubes MAWP 56 PSI@122F. National Board #10. Serial #06D058-H1608. Built 2008. Past use Product condenser.

Used 1130 sq ft shell and tube heat exchanger. Manufactured by Camden Alloy Fabricators. (434) 316SS tubes rated 200 psi @500F. Carbon Stell shell rated 200 psi @600F. Tube 1.25"dia x 8' length. 3'shell dia x 12'4" overall length.

Used 1130 Sq Ft 304L Stainless Steel Shell and Tube Heat Exchanger. (148) .75" tubes rated 150PSI@300F. Shell rated 150PSI/FV@300F. National board rated. Built 2012.

Used 1120 Sq Ft Stainless Steel Horizontal Heat Exchanger. 316-SS Shell rated 150/FV PSI @ 250 deg F, 316-SS Tubes rated 100 PSI @ 200 deg F. No Heads. 2' 3" Shell dia. x 14' 6" L. (476) .75" dia Tube Holes, 12' 2"L. Shell: 4 pass, Tubes: 1 pass. Shell Nozzles: 4", 2". Built by Atlas 1992, S/N: 8267, NB# 6961.

Used 1099.6 Sq Ft Stainless Steel Shell and Tube Heat Exchanger. Mfg Henry Tech. 304 SS. Shell rated 350/FV@200F. (280) .75" x 240"L Tubes rated 150PSI@200F. Serial #C350160E-1. National Board #26434 (dup). Built 2015.

Used 1089 sq ft stainless steel shell and tube heat exchanger. Manufactured by Hoffman Process. 304L SS shell rated 150psi @450F. (231) 1" 316L SS tubes rated 150psi @150F. National Board #808. Serial #3185B. Built 2000.

Used 1089 sq ft stainless steel shell and tube heat exchanger. Manufactured by Hoffman Process. 304L SS shell rated 150psi @450F. (231) 1" 316L SS tubes rated 150psi @150F. National Board #806. Serial #3185A. Built 2000.

Used 966 sq ft 316L stainless steel horizontal shell and tube heat exchanger. Manufactured by Ward Tank and Heat Exchangers. 316L stainless steel heads. (328) 3/4" diameter 316L stainless steel tubes, rated 150 psi @-20 to 302F. SA-516-70 Shell, rated 150 psi @-20 to 302F. National board #3637, serial #HC-6168. Built 2006.

Used 942 SQ Ft 316L Stainless Steel Vertical Shell and Tube Heat Exchanger. Mfg Puget Equipment Co.(Div of JBL International). 316L SS Shell rated 15PSI@450F. (200) .75"OD 316L SS Tubes Rated 15PSI@450F. (4) Lug mounted. Serial #98301. National board #4385. built 1998. Weight 4000 lbs

Used 900 Sq.Ft. Shell and Tube Heat Exchanger. Built by Enerquip. Sanitary 304L Stainless Steel. TUBES: (236) 3/4" x 239" (8) Pass rated 150 PSI @ 375 Deg.F. SHELL is 20" Dia. rated 150 PSI @ 375 Deg.F. Tube inlet/outlet 2.5". Shell inlet/outlet 4". Built to 3-A Dairy Standard. Exterior side finish 40 Ra max. Product side finish 32 Ra max. Built 2014. NB Stamped.

Used 745 sq ft stainless steel shell and tube heat exchanger. Manufactured by Pfaudler. Shell rated 100 psi @250F. (488) 1" O.D 316 stainless steel tubes, rated 100 psi @250F. 32" OD x 127 1/2" Length. Weight 4465 lbs. National Board #46860. Serial #R392-1806. Built 1992.

Used 730 Sq. Ft. Horizontal Heat Exchanger, Approximately 14" Diameter X 14' Straight Side. T304 Stainless Steel Tubes. T304 Stainless Steel Shell And Carbon Steel Heads. (Note: Pressure & Temp Unavilable - No Name Plate)

Used 690 Sq. Ft. Stainless Steel Horizontal Shell and Tube Heat Exchanger. CS Shell Side rated 75 PSI @ 300 deg F; 304-SS Tubes rated 100 PSI @ 150 deg F. SS Tubesheets, CS Heads. 220 Tubes @ 3/4: dia. x 16' Long. Shell-1 pass, Tubes-2 pass. Shell inlet/outlet - 10". Tube inlet/outlet - 2". Mfg: Heat Exchangers Inc. Size 17-192, S/N: 128.

Used 690 Sq.Ft. Shell and Tube Heat Exchanger. Enerquip Sanitary 304L Stainless Steel. TUBES: Approx (178) 3/4" x 239" (8) Pass rated 150 PSI @ 375 Deg.F. SHELL is 18" Dia. rated 150 PSI @ 375 Deg.F. Tube inlet/outlet 2.5". Shell inlet/outlet 4". Built to 3-a Dairy Standard. Exterior side finish 40 Ra max. Product side finish 32 Ra max. Built 2014. S/N: 16567. NB# 14297.

Used 602 sq ft stainless steel shell and tube heat exchanger. Manufactured by Manning & Lewis. 316 SS shell rated 100psi @375F. (438) .75" 316SS tubes rated 100psi@ 375F. NB #6545. Serial #13593. Built 1987.

Used 600 sq. ft. Pfaudler Heat exchanger. (680) 3/4" diameter stainless steel tubes x 4-1/2' long in 28" diameter single pass carbon steel shell. Both heads missing. Rated 75 PSI @ 350 deg. F. on both sides. Pfaudler serial number 42038.

Used 561 Sq. Ft. Southern Heat Exchanger Corp. 304L Stainless Steel Horizontal Shell & Tube Heat Exchanger. Shell rated 100 PSI @ 200 deg F; Tube side rated 85 PSI @ 150 deg F. (143) .75" dia straight 304 L SS Tubes with 20' length; 14' x 22' 5.75", 3/16" shell. Serial # 78-117; National Board # 2721; Built 1978. Nozzles: Shell side: (2) - 3" Tube side: (2) - 3". Estimated Weight: 3,400 lbs. Note: Failed Hydro Test - needs repair.

Used 166 Sq Ft 304 Stainless Steel horizontal Shell and tube heat exchanger. Manufactured by Perry Products. Type CEN. (127) .625"OD 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI@300F. 12'Dia x 8'F/F. 1100 Lb.

Used 416 Square Feet Rubicon Ind. Corp. Shell & Tube Horizontal Heat Exchanger, U-Tube type, model # VS18BU4-192H, carbon steel shell rated for: FV & 100 PSI @ 300 Deg. F., stainless steel tubes rated for: 100 PSI @ 200 Deg. F., Dimensions approximately 18" dia. x 20' O.A.L. Serial #1746-1, National Board #903, Year Built: 1989

Used 416 Sq Ft 316L Stainless Steel Vertical Shell and Tube Heat Exchanger. Manufactured by Rubicon. Shell Rated 150 PSI@300F. (212) .75" OD Tubes rated 150PSI/FV@300F. 16" OD x 156.25" OAL. Serial #4213. Built 2016.

Used 350 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Patterson Kelley. 316SS Shell rated 60 psi/fv @300F. (164) 1" dia 316SS tubes rated 60psi @120F. Serial #210927. National Board coded. Built 1970.

Used 340 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Kam Thermal. 316 SS Shell rated 90 psi @390F. (206) 0.75" 316SS tubes rated 90PSI @390F. Serial #6617. National Board #749. Built 1986.

Used 320 Sq Ft Stainless Steel Horizontal Shell and Tube Heat Exchanger. Manufactured by Perry Products. Carbon Steel shell rated 90 psi @ 390°F. 316 Stainless Steel tubes rated 90 psi @ 390°F. (196) 0.75" dia 316SS tubes with a 15/16" triangular pitch and 0.049" wall thickness, 8'2" long, 4 passes. Shell diameter: 1'6". National Board coded.

Used 297 square feet T304 stainless steel shell and tube heat exchanger. Manufactured by Perry Products. (126) T304 Stainless steel tubes, 3/4" diameter X 12' long, rated 75 psi /FV @ 320F. Shell carbon steel 12" diameter X 12' long, rated 75 psi /FV @ 320F. T304 Stainless steel heads. Horizontal design. Expansion Joint. Shell 2-pass. Serial #B2770. National Board #2410. Built 1980.

Used 270 sq ft 304 Stainless Steel shell and tube heat exchanger. Manufactured by Perry Products. (206) .625"OD 304 SS Tubes rated 44PSI/FV@334F. 304 SS Shell rated 85PSI@334F. 8'F/F.

Used 223 sq ft stainless steel shell and tube heat exchanger. Manufactured by Doyle & Roth. 14" OD x 43' length. Carbon steel shell rated 150psi @375F. (85) 1" 316SS tubes rated 150psi@ 450F. Built 1979. Weight 1700 lbs.

Used 264 sq ft stainless steel shell and tube heat exchanger. Manufactured by Manning & Lewis. Carbon steel shell rated 150psi @375F. (126) 1" 316SS tubes rated 150psi@ 375F. Built 1971.

Used 235 square feet vertical exchanger. Manufactured by JD Cousins Inc. Shell rated 100 psi @ 350F. T304 Stainless Steel Tubes rated 15/FV @ 300F. (30) 2" tubes X 0.065". Stainless steel heads. Carbon steel shell 18" X 15' long. Lug Mounted. National Board #7677. Serial #1202-13. Built 2003.

Used 214 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Doyle & Roth. 316SS Shell rated 90 psi/fv @300F. (136) 1" dia 316SS tubes rated 90psi/fv @300F. Serial #J-4327-1. National Board #12379

Used 200 sq ft 304 Stainless Steel shell and tube heat exchanger. Manufactured by Perry Products. (153) .625"OD 304 SS Tubes rated 44PSI/FV@334F. 304 SS Shell rated 85PSI@334F. 8'F/F.

Used 200 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Kam Thermal. Shell rated 90PSI. Serial #66103. National Board coded.

Used 200 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Kam Thermal. Shell rated 90PSI. Serial #66100. National Board coded.

Used 166 Sq Ft 304 Stainless Steel horizontal Shell and tube heat exchanger. Manufactured by Perry Products. Type CEN. (127) .625"OD 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI@300F. 12'Dia x 8'F/F. 1100 Lb.

Used 162 sq ft 304 Stainless steel shell and tube heat exchanger. Manufactured by Perry Products. Type CEN. (122) .625"OD 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI@300F. Weight 1100 lb.

Used 120 sq ft 304 Stainless Steel shell and tube heat exchanger. Manufactured by Perry Products. Type CEN. (92) .625" 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI@300F. 10"Dia x 8'F/F. 875 lb.

Used 120 sq ft 304 Stainless Steel shell and tube heat exchanger. Manufactured by Perry Products. Type CEN. (92) .625" 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI@300F. 10"Dia x 8'F/F. 875 lb.

Used 110 sq ft 304 Stainless Steel shell and tube hea exchanger. Manufactured by Perry Products. (121) .625"OD 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI@300F. 10"Dia x 8'F/F. 875 lb.

Used 110 Sq ft 304 Stainless Steel shell and tube heat exchanger. Manufactured by Perry Products. (84) .625"OD 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI@300F. 10"Dia x 8'F/F. 875 lb.

Used 102 sq ft 316L stainless steel horizontal heat exchanger. Mfg. by Perry Products. Model #12-102. 316L SS shell rated 150FV @320F. (104) 316L SS tubes rated 150 psi @320F. 12" diameter x 5' tube length. Built 1995.

Used 92 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Perry Products. 316SS Shell rated 90 psi/fv @300F. (44) 1" dia 316SS tubes rated 90psi/fv @300F. Serial #B-3887. National Board #3347.

Used 92 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Kam Thermal. 316 SS Shell rated 90PSI @390F. (56) 316 SS tubes rated 90PSI @390F. 10" dia x 9'10" length. Serial #6614. National Board #746. Built 1986.

Used 92 sq ft stainless steel shel and tube heat excahnger. Manufactured by Kam Thermal. (56) 0.75 dia 316SS tubes rated 90 psi @390F. 316SS Shell rated 90psi @390F. Overall L 9'10". Shel diameter 10". Srila #661, NB #743. Built 1983.

Used 92 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Doyle & Roth. 316SS Shell rated 90 psi/fv @300F. (44) 1" dia 316SS tubes rated 90psi/fv @300F. Serial #J4327-2. National Board #12380.

Used 92 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Kam Thermal. 316 SS Shell rated 90PSI @390F. (56) 316 SS tubes rated 90PSI @390F. 10" dia x 9'10" length. Serial #6612. National Board #744. Built 1986.

Used 92 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Perry Products. 316SS Shell rated 90 psi/fv @300F. (44) 1" dia 316SS tubes rated 90psi/fv @300F. Serial #B-3887. National Board #3347.

Used 90 Sq Ft 316 Stainless Steel Horizontal Shell and tube heat exchanger. Manufactured by Patterson Kelly. 316SS Shell rated 60 psi/fv #140F. (44) 1" dia 316SS tubes rated 60psi @100F. Serial #210928. National Board coded.

Used 56 sq ft Stainless steel horizontal shell and tube heat exchanger. 8" dia 316SS shell rated 90 psi @390F. (34) 0.75 dia 316 SS tubes rated 90 psi @390F. Built in 1989.

Used 46 sq ft 304 Stainless Steel vertical Shell and tube heat exchanger. Built by Perry Products. Type CEN. (35) .625"OD 304 SS tubes rated 35PSI/FV@300F. 304 SS Shell rated 85PSI @ 300F. 10"Dia x 8'F/F. 575 lb.
