3000 gallon vertical glass lined, agitated, jacketed reactor. Manufactured by Pfaudler, type RS-96-3000-100-100, Serial# J016978, NB# 49171, built 1998. ASME code stamped for 100 psi or 85 psi with FV @ 500/-20 deg. F internal. Jacket rated 100 psi or 85 psi with FV @ 550/-20 deg. F. With Glass 3619 Delta Glass blue. 8' diameter x 77" straight side. Welded dished heads. Overall reactor height 200". Mounting lugs. Equipped with CRYOLOCK nucerite 41" span curved blade turbine impellor, driven by 6RWF-SFM agitator drive, fan cooled, 18:1 ratio with Crane 8-9 stack up mechanical seal with lubricator. Agitator driven by 20 hp, 3/60/230/460V, 1800 rpm TEFC class 1, Div. 2, group D motor. Agitator output speed 97 rpm. With fin baffle with single element American Standard tantalum encased thread with TRD sensor. Openings: Top - 24" manway with cover and 1-4" sight glass, protecting ring and SS spring assist, 1-12", 1-8", 2-6", 4-4"; Bottom 1-4" center.
