7188 CFM Ariel JGT/2 Reciprocating Compressor
Other Views - click image for larger view
7188 CFM Ariel JGT/2 Reciprocating Compressor 7188 CFM Ariel JGT/2 Reciprocating Compressor 7188 CFM Ariel JGT/2 Reciprocating Compressor 7188 CFM Ariel JGT/2 Reciprocating Compressor 7188 CFM Ariel JGT/2 Reciprocating Compressor

7188 cfm ariel jgt/2 reciprocating compressor

Stock # 16007
Capacity 7188 CFM

Overview

Used Ariel Corporation Model JGT/2 Reciprocating Gas Compressor. 7188 SCFM. Past use: Syn Gas Compressor. Frame Model JGT/2. 4.5" clockwise stroke @1500RPM. Drive rated 850HP @890RPM. Max Rod Load Tension 37000 lbs. Max Rod Load Compression 40000 lbs. (2) Throws - #1 MODEL #14-1/8T-PRC; 13.625" BORE; 577.3 RDP. #2 MODEL #17-7/8T-PRC; 17.375" BORE; 404.5 RDP. MAWP 445PSIG. Crankshaft Centerline 17" from Bottom. Serial #F-50488. Built 2015. Skid Weight 15860 lbs

Share
SPECIFICATIONS TERMS & CONDITIONS
Manufacturer
Ariel
Model
JGT/2
Material
Unknown
Capacity
7188 CFM
Category
