1600 KW Jenbacher Gas Engine & Generator

1600 kw jenbacher gas engine & generator

Stock # 13827
Capacity 1600 KW

Overview

Used 1.6MW Natural Gas fired power plant. Powered by (2) Jenbacher 1000HP Model J316GSB86 NG engines. Model #s 3699171 and 3693861. Both output 800kW. Firing order 1-5-7-3-8-4-2-6. Newage A/c Generator Machine ID # 02431784 and 02431785, 1050 KW Continuous/3ph/60hz. Power factor .8. Exciter: 3.5 Amps, 59V. Ambient Temp 40C. Stator winding 12. Controlled by DiaNE Computer and Control system. Jenbacher model IC-912 ignition controller and Woodward speed control. 3MW Transformer - 480V/3ph step to 12KV. Switchgear: (5) Model NEMA-TYPE -3R. 3ph/3W/60Hz Max 480V. Horiba Emission Control System. Engine 1 - 70179Hrs. Engine 2 - 68373 Hrs. Built 2002. With enclosures. Last Run Jan 2017.

Share
SPECIFICATIONS TERMS & CONDITIONS
Manufacturer
Jenbacher
Model
J316GSB86
Material
Unknown
Capacity
1600 KW
