Used Chart Process Equipment

Phoenix Equipment has a large inventory of used, unused, and reconditioned equipment from Chart. Phoenix Equipment offers a wide selection of categories from Chart. If you can't find the exact Chart equipment you are looking for, contact us and we can help you find it.

Categories
Featured Equipment for Sale
49256-sq-ft-chart-fin-fan-heat-exchanger
49256 Sq Ft Chart Fin Fan Heat Exchanger
Stock# 17527 Capacity 49256 Sq Ft

Used 49256 Sq Ft Chart Cooler Service Co. Inc Air Fin Cooler. Model 1-HF120-2-40. Tube bundle 11' wide X 40' long. (222) Carbon steel 1" tubes with L-tension wrapped aluminum fins. 4 rows, 3-passes. 2313 sq. ft.(Bare). 49256 Sq Ft (extended). 500 PSIG @450F. 8" 300 lb inlet and outlet and 1" vent and drain. (2) 25 HP 10'Dia Moore model 10000-30 EC VT fans. (5) blades each with 6.9 pitch with 28,200 ACFM/fan. Output 323.2 RPM. 25HP 3/60/460. Overall dimensions 42' long X 11' wide X 11'8" tall. Weight 27,000#. Previous use natural gas service. National Board # 15571. Serial #32312-1. Built 2012.
