NGL & Condensate Stabilizer - 5,000 BPD
Other Views - click image for larger view
NGL & Condensate Stabilizer - 5,000 BPD NGL & Condensate Stabilizer - 5,000 BPD NGL & Condensate Stabilizer - 5,000 BPD NGL & Condensate Stabilizer - 5,000 BPD NGL & Condensate Stabilizer - 5,000 BPD

NGL & Condensate Stabilizer - 5,000 BPD

Stock # 569
Capacity 5,000 BPD
Products Natural Gas Liquids

Overview

The stabilizer system consists of a feed-bottom exchanger (to maximize the heating efficiency and minimize the fuel gas consumption and product cooling cost), a stabilizer column with valve trays (for vapor-liquid contacting), reboiler (to warm up the hydrocarbon liquids and vaporize the light hydrocarbons using a heat medium), and a product cooler (to reduce the temperature of liquid products). Hot vapor, which is produced in the reboiler, flows up the column, stripping out the light hydrocarbons (e.g. C1, C2, C3, etc.) from the relatively colder liquid stream flowing down from the top of the tower to produce a stabilized liquid product. The overhead vapors may be used as fuel gas or recompressed into the sales gas pipeline or the front of a gas processing facility.

Major Equipment

NGL separator
Stabilizer
Stabilizer reboiler
Feed preheater exchanger
Overhead compressor
Expansion tank
Relief vessel
Share
SPECIFICATIONS RESOURCES
Year Built
2016
Year Shut
Capacity
5,000 BPD

For additional information, visit the Resource Center
