2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer
Other Views - click image for larger view
2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer 2000 Gal SANICRO 28 ALLOY SaniFab Evaporator Crystallizer

2000 gal sanicro 28 alloy sanifab evaporator crystallizer

Stock # 5167
Capacity 2000 Gal

Overview

USED 6' x 8' CRYSTALLIZER SYSTEM, WITH AGITATOR AND COIL, DESIGNED FOR CRYSTALLIZATION OF TARTARIC ACID, BATCH-TYPE, 2,000 GALLONS PER 4-6 HOURS. COMPLETE WITH CRYSTALLIZER BODY CONSTRUCTED OF SANICRO 28 ALLOY, RATED FOR FULL VAC INTERNAL, MEASURES 6' DIA. X 8' STRAIGHT SIDE, DISHED TOP & BOTTOM, (2) SETS OF INTERNAL COILS, CENTER TOP AGITATION WITH PADDLE AGITATOR, DRIVEN BY APPROX. 2 HP MOTOR THRU GEAR BOX, 6" CENTER BTM. OUTLET, 2" FEED INLET WITH MANUAL VALVE, 18" TOP MANWAY & 16" TOP VENT, EACH HAVE A STEAM JET VACUUM EJECTOR. GASES ESCAPE THROUGH VENT OPENING TO (2) ELEVATED EVAPORATOR BODIES MEASURING APPROX 36" DIA. X 6' HIGH EACH. SECOND BODY INTRODUCES WATER THROUGH PLATES TO CREATE SUCTION AND CONDENSE GASES. ALSO INCLUDES VACUUM PUMP. STILL INSTALLED AND APPEAR TO BE IN GOOD CONDITION. (QTY - 4 AVAILABLE)

Share
SPECIFICATIONS TERMS & CONDITIONS
Manufacturer
SaniFab
Model
NA
Material
SANICRO 28 ALLOY
Capacity
2000 Gal
Category
