1 MW Capstone C1000S Micro Turbine Generator
Other Views - click image for larger view
1 MW Capstone C1000S Micro Turbine Generator 1 MW Capstone C1000S Micro Turbine Generator 1 MW Capstone C1000S Micro Turbine Generator 1 MW Capstone C1000S Micro Turbine Generator 1 MW Capstone C1000S Micro Turbine Generator

1 mw capstone c1000s micro turbine generator

Stock # 21638
Capacity 1000 KW

Overview

Unused 1 MW Micro Turbine Generator. Manufactured Capstone (Green Energy). Model #C1000S, designed for landfill gas feedstock. 400/480V-3Phase-4 wire wye. Electrical Service, 50/60 Hz Frequency, 33% Electrical Efficiency LHV. Fuel/Engine Characteristics: 13.0-22.4 MJ/m3 (350-600 BTU/scf) Landfill Gas HHV, <5,000 ppmv H2S Content, 517-551 kPa gauge (75-80 psig). Inlet Pressure, 12,000 MJ/hr (11,400,000 BTU/hr) Fuel Flow HHV, 10.9 MJ/kWh (10,300 BTU/kWh) Net Heat Rate LHV. Exhaust Characteristics: <9 ppmvd (18 mg/m3) NOx Emissions @ 15% O2, 6.7 kg/s (14.7 lbm/s) Exhaust Mass Flow, 280 deg. C (535 deg. F) Exhaust Gas Temperature. 117” W x 360” D x 119” H. 17,100 kg (37,700 lbs) Weight . Built 2023.
