1979 Sq Ft Melter SA de CV Stainless Steel Shell & Tube Heat Exchanger
Other Views - click image for larger view
1979 Sq Ft Melter SA de CV Stainless Steel Shell & Tube Heat Exchanger

1979 sq ft melter sa de cv stainless steel shell & tube heat exchanger

Stock # 16317
Capacity 1979 Sq Ft

Overview

Unused 1979 sq. ft. Melter SA de CV 304 Stainless Steel Shell & Tube Heat Exchanger. 1 pass shell side. 12 pass tube side. Type NEN, Horizontal. Stainless steel shell rated 120 psi / F.V. at 250 degrees F. (252) 1-1/4” O.D. x 24’ long. 16 BWG (0.065” AW) 304 stainless steel tubes rated 150 psi at 250 degrees F. 304 stainless steel expansion joint (bellows). 304 SS tubesheet. Openings shell (2) 20” and (1) 6”, opening for tubes (2) 6”. Flat bolt on stainless steel linner ends with davit arms. Mounted on carbon steel saddles. Serial# MDI-333-6. National Board #225. Built 2007.

Share
SPECIFICATIONS TERMS & CONDITIONS
Manufacturer
Melter SA de CV
Model
NEN
Material
304 Stainless Steel
Capacity
1979 Sq Ft
