1500 Gal Carbon Steel Pressure Vessel

1500 gal carbon steel pressure vessel

Stock # 3301
Capacity 1500 Gal

Overview

Used 1500 Gallon Vertical Closed Top Pressure Rated Storage Vessel, 60" Diameter X 10' Straight Side W/ Dished Heads. For 15 PSI@ 400 F. 20" Side Bottom Manway W/ 3" Cover Outlet Flanged, 1 Bottom Side Outlet Flanged, 4" Ctr Bottom Outlet Flanged W/ Reducer To 1.5", 1 - 1.5" Off Ctr. Bottom Connection, 2 Top Flanged Connections, Mounted On (4) 6" Channel Legs W/ 16" Floor Clearance Tank Rated For 15 PSI@ 400 F.

Share
SPECIFICATIONS TERMS & CONDITIONS
Manufacturer
Unknown
Model
N/A
Material
Carbon Steel
Capacity
1500 Gal
