Used 4m3 316L Stainless Steel Nauta Dryer/Mixer. Manufactured by Titus (Krauss-Maffei). Model TMT-4/300. 20 HP Bottom driven orbital arm drive. Vertical configuration. 300 mm screw diameter. 13.5m heat transfer. 304L stainless steel half pipe coil jacket on shell OD and top head. Internal rated 101PSI/FV@392F. 304L SS Jacket rated 101PSI @ 392F. Includes top mounted filter housing. Serial #7051.
Used 1400L Vacuum Dryer. Manufactured by Krauss Maffei. Model MT 1/200.. Constructed of 316L stainless steel. Interior has polished surface. Conical vessel has a capacity of 49.43 cu ft with working volume of 35.3 cu ft. Dryer uses an 8" diameter inclined orbiting screw, driven by a 10 HP drive to gently agitate product while drying. Can dry particles up to 5 mm in size. Rated for Full Vacuum/150 psi @ 450f on jacket and internal. Drying temperature maximum is 302 f. The top has an 18" manway with 6" sight glass, 18" flanged fitting, 4" sight glass, (2) 3" flanged fittings, (2) 2" flanged fittings, 6" flanged fittings and (2) 1" threaded fitting for the top jacket. The side has (2) 2" flanged fittings for the body jacket. The bottom has a 10" flanged discharge fitting with pneumatically operated flush mount valve and (2) 1" threaded fittings for bottom jacket. Serial # 7098. National Board # 21424.
Used 141 Cu Ft (4m3) 304L Stainless Steel Nauta Mixer/Dryer. Manufactured by Krauss Maffei. Model MT 4/300. 400 liter capacity. Shell rated FV. Half pipe Jacket rated 44PSIG. 300mm dia conical orbital screw. 20HP Orbital arm drive. 15 HP screw drive. includes Top mounted 52 sq ft filter. Serial #4148/2640. Built 1991.
Used 250 Liter 316Ti Conical vacuum dryer. Manufactured by Krauss Maffei Verfahrenstechnik GmbH. Type TMD 0,25/160 “Titus-Mixer-Dryer”. Mach.No. 7005/742904/3. Working pressure 3 Bar, Vacuum possible. Working pressure jacket 6 Bar. Capacity 380 Ltr. Useful capacity 250 Ltr. Largest cone diameter 1016mm. Cone height 1066mm. Dished top. Stainless steel arm. Mixing screw jacketed (6 Ltr). Motor 4.0 KW + 1.5 KW. 380 Volt (Ex). With jacket (96 Ltr). Max. temperature 165C. Bottom outlet dia. 150mm. Built 1995. Mounted on frame. Includes switchgear. Floorspace 2m x2m, Total height 3.5m. Weight 2650kg, ATEX compatible
