Used 14381 gallon 304 Stainless Steel tank. 13'Dia x 19'tall. Flat bottom, dished top. Side manway.

Used 12500 Gallon Stainless Steel Insulated Tank. Measure approximately 12' diameter x 14'6" high, flat bottom. Past use sucrose and corn syrup storage tank. Catwalk and ladder not available.

12,000 litre stainless steel vertical tank. Unit measures approximately 2300MM diameter x 3000MM straight side. Has welded flat top and welded cone bottom heads. Unit is mounted on 4 legs. Fitted with side access ladder and safety rail.

Used 11500 Gallon (376 BBL) stainless steel tank. 11' diameter. Mounted on carbon Steel Skirt. Dish Bottom and Top. Previous use: storage tank in a brewery. (2) tanks available.

Used 11500 gallon (370 BBL) stainless steel mixing tank. Explosion proof (XP) Side Entering Alsop Model 200 Mixer. 2HP/208-230/460 volt. 1725 RPM. 10'6" Dia x 23' Tall. 4" Center bottom outlet. Previous use: Mixing Tank in a brewery. (6) Available.

Used 10500 gallon stainless steel mix tank. 12' diameter x 13' straight side, slight cone top, flat bottom with sump discharge, bridge mounted Chemineer agitator drive, model 6HHTD-15, 15 HP, 230/460 volt motor, 30 RPM output speed, two tiered 3 blade pitched turbine agitator, 20" top manway, 18" side bottom manway.

Used 10000 Gallon Stainless Steel Storage tank. Cone top and Flat bottom. 11'6" Dia.x 13'10" plus cone top. Last use IPA (Isopropyl Alcohol).

Used 8600 gallon stainless steel tank. 94"D x 24'Straight side. Sloped bottom slight cone top. 3" side bottom outlet. Side manway with cover. Past use Juice Facility.

Used approximately 8000 gallon vertical 304 stainless steel tank. 10'diameter X 14' high straight side. Slight cone top, flat bottom. Top fittings: (3) 8", (1) 6", (2) 2", and (1) 4". Has (3) 1.5" side pad style inlets, (1) 6" side pad style outlet, (1) 8" side bottom pad style outlet, and (1) 4" side bottom outlet. Has internal coil. Covered with 3" insulation and sheathing.

Used 6391 gallon 304 stainless steel vertical mixing tank. Internal coils, insulated. Top mounted agitator, 2" 304 stainless steel coil. Atmospheric pressure. (4) internal sidewall baffles. Flat top and dished bottom. On lug supports.

Used 5800 gallon Stainless Steel mixing tank. Top entering 4-blade agitator 10hp motor. Internal baffles. (4) Leg mounted. Dome top, dish bottom. Top manway. Dimensions: 13'H X 105"D

Used 5000 gallon Stainless Steel vertical tank. Side entering manway. (4) leg mounted.

Used 4750 Gallon, 304 Stainless Steel, Vertical Tank. 84" Diameter x 200" straight side, flat top, sloped bottom. Internal sidewall ladder. Openings top 1-1/2" tri-clamp, (2) 2" NPT, 3-1/2" threaded, 20" man way with cover. 2-1/2" Off center bottom outlet. Mounted on 4 carbon steel legs with skirt. No manufacturers tag. Previous use: water storage for brewery.

Used 4500 gallon stainless stell mix tank. 7'6"ID x 14' Straight-side (OAH 18'). Flat top, slight cone bottom with 2” diameter center bottom discharge. Top head includes MixMor Model T0B-2-N20 bridge mounted, top entering agitator drive and a partial hinged lid. Agitation includes a stainless steel shaft and two 4-blade pitched turbine bolted paddles, driven by 2 HP, 208-230/460V, 1725 RPM, 3/60Hz motor thru Falk gear reducer. (4) Leg mounted.

Used 3900 gallon 304 Stainless Steel Vertical Mix tank with internal coil. 304SS coil, insulated. Shell rated ATM @475F. Top Mounted Agitation, (4) Internal Sidewall Baffles, Flat Flanged Top & Dished Bottom.

Used 2750 gallon stainless Steel tank. 7'6"ID x 8'Straight-side (OAH 10'4"). Flat top with (2) Partial hinged lids and Cone bottom with 2" Center Bottom outlet. 2HP side entering agitator. (4) Leg mounted.

Used approximately 2500 gallon vertical 304 stainless steel tank. Approximately 84" diameter X 9' 4" straight side. Open top. Flat bottom. Center bottom outlet.

Used 2250 gallon Stainless Steel Mix tank. 6’ID x 8’3” straight side (16'OAH). Dish top and dish bottom. 15” diameter flange connection to 2” diameter pipe discharge. Top-entering, flange-mounted agitation with stainless steel shaft and two 3-blade stainless steel props, driven by 3 HP, 208-220/440V, 1760 RPM, 3/60Hz motor. 18” diameter top-entering manway with six top inlets two 4”, two 2” & two 1 1/2”. Lug Mounted within mild steel frame with (4) legs and footpads.

Used 2000 Gallon Stainless Steel Agitated Tank. 6’4” diameter x 8’ straight side (10"9' OAH) with a slight cone top and slight cone bottom, 2 1/2” diameter center bottom discharge with a 90-degree elbow. Side-entering agitator connected to flange connection. Agitator driven by 2 HP motor. Top head includes 18” diameter manway and two 2-1/2” diameter openings. Straight side includes side ladder with step platform. (5) Leg mounted.

Used 2000 gallon Stainless Steel agitated tank. 6'D x 10' Straight side (12' OAH). Cone top, sloped bottom with 2" side discharge with manual valve and sample port with valve. 2HP Side entering agitator. 18" Top manway and (2) 2" openings. (6) Leg mounted.

Used 1200 gallon vertical stainless steel vessel. 304 stainless steel. Dished heads. On leg supports.

Used 900 gallon stainless steel mix tank. 46"ID x 10' s/s (11'7" OAH). flat top and dish bottom with 3" CBO. MixMor Model T0-1.5 top-entering, bridge-mounted agitation with stainless steel shaft and three 4-blade stainless steel bolted pitched-turbine blades along common stainless steel shaft, driven by 1.5 HP, 230/460V, 1740 RPM, 3/60Hz motor. (4) Leg mounted.

Used 850 gallon open top jacketed stainless steel sanitary mixing tank, dimple jacket body with independent jackets on wall and bottom, side wall is shrouded and insulated and had been in house pressure tested to 20 psi, bottom jacket is open and exposed from previous repair and testing shows multiple leaks which are repairable, 66" id x 58" deep with flat sloped bottom to 2" discharge with npt connection (can be changed to food service) with 12" floor clearance, central bridge with 1. 5 HP gear motor 208-220/440/3 phase voltage by master @ 18 rpm driving paddle agitator with retreating curves (as modified for former usage), dual hinged covers. Formerly used in food ingredients.

Used 770 gallon 304 Stainless Steel tank. Flat top, dish bottom. Lug mounted. Agitator. Past use Recovered Slurry tank

Used 770 gallon 304 Stainless Steel tank. Flat top, dish bottom. Lug mounted. Agitator. Past use Recovered Slurry tank

Used 750 Gallon SS Tank. Flat bottom, open top with center top entering agitator on bridge mount support. Driven by 3 HP motor thru gearbox. Includes internal baffles and (2) 2" diameter outlets. (#1) tank is a storage tank. (#2) tank is an agit. tank. (#3) tank is agit. with (8) Krebs hydrocylclones mounted above. (#4) tank is agit. with (2) Krebs hydrocyclones mounted above. Previously used as decanter tanks. Qty (4) available.

Used Stainless Steel 650 gallon dimple jacketed tank measuring 52" diameter x 70" straight side with dish top and bottom, has 19-1/2" top manway, (2) 2" and 1-1/2" tri-clamp top ports and 2" center bottom discharge. Unit is on (4) 3" legs.

Used 600 gallon stainless steel open-top tank. 52'D x 5' straight side (6'9"OAH). Slight cone bottom with 2.5" Center bottom outlet with manual valve. (4) Leg mounted.

Used Piersol Pine MFG approximately 560 gallon vertical 304 stainless steel mix tank. S/N: 9144-A. 60” diameter X 46” high straight side. Internal rated 2 PSIG @ 212 degrees F. Unit has bolt on dished top, dished bottom. S/N: 9144-A. Top fittings: 14" X 10" manway (no cover), (2) 2.5", (1) 3", (1) 4", and (1) 1". 1.5" center bottom drain with flush valve. Equipped with heavy anchor style agitator driven by a Philadelphia 5MVG-2 drive, S/N: 515246, Ratio 14-1, powered by Reliance 10 HP, 3/60/230-460 volt motor. Mounted on legs (that were removed to aid in removal of tank).

Used Approx 500 gallons Stainless Steel Vertical Storage Tank. (4) Leg mounted.

Unused 400 gallon Stainless Steel Tank. With 720 gallon - 5'3" wide x 5'3" long x 3'6" deep secondary containment.

Unused 400 gallon Stainless Steel Tank. With 720 gallon - 5'3" wide x 5'3" long x 3'6" deep secondary containment.

Unused 200 gallon Stainless Steel Tank. With 460 gallon - 4'6" wide x 5'6" long x 2'6" deep secondary containment.

Used 10 bbl (300 gallon) stainless steel jacketed Brite tank. 34"D X 96"H straight side 128"OAH. Dished top and bottom. Top fittings: Center 3.75" sanitary with a spray ball fed by 1.25" sanitary pipe. (1) 1.75" sanitary with a sanitary pressure relief. Spray ball line with side top connection for side level indicator. (5) side bottom 1.25" sanitary outlets. Has (1) 13.5" X 17.5" side bottom manway. 1.25" center bottom drain. (2) zone side jacket and bottom jacket. Mounted on (4) legs with levelers. Previously used for craft beer. (4) Available.

Unused 200 gallon Stainless Steel Tank. With 460 gallon 4'6" wide x 5'6" long x 2'6" deep secondary containment.

Used 200 Gal Stainless Steel Single Wall Vertical Balance Tank. 3 hp Centrifugal Pump with Baldor 3450 RPM Motor, 208-230/460 Volts, 3 Phase.

S/S COP Tank, with Ampco 10 hp Centrifugal Pump, 3500 RPM Motor, Internal Dims.: Aprox. 134-1/2" L x 16" W x 11" H, with Spray Jet, Mounted on S/S Portable Frame (CP COP #13) (LOCATED IN CHAMPAIGN, IL)

Used 100 gallon vessel. 316L stainless steel.

Used 75 gallon Stainless Steel tank. 24"Dia x 36"H. 7" Cone bottom. (4) Leg mounted.

Used 50 Gal. S/S Single Wall Tank, with Cone Bottoms, Mounted on S/S Platforms on Load Cells, Internal Tank Dims.: Aprox. 26" Tall x 23-1/2" Dia., with S/S Hinge Lids (Scale Tank #1/Cookers 3-4 & Tank 1)

Aprox. 50 Gal. S/S Single Wall Tanks, with Cone Bottoms, Mounted on S/S Platforms on Load Cells, Internal Tank Dims.: Aprox. 27-1/2" Tall x 22-1/2" Dia., with S/S Hinge Lids (LOCATED IN CHAMPAIGN, IL)

50 Gal. S/S Single Wall Tank, with Cone Bottom, Mounted on S/S Legs & Load Cells (LOCATED IN CHAMPAIGN, IL)

S/S COP Tank, Internal Dims.; Aprox. 41" L x 20" W x 14" Deep

Aprox. 35 Gal. S/S Single Wall Vertical Tank, Internal Dims.: Aprox. 36" Tall x 17-1/2" Dia., Mounted on S/S Base (LOCATED IN CHAMPAIGN, IL)

(2) Portable S/S Troughs, Mounted on Portable S/S Frame (LOCATED IN CHAMPAIGN, IL)

Used Stainless Steel Dimple Jacketed vertical tank. (4) leg mounted.

Used vertical stainless Steel tank. Dished top and bottom. Leg mounted.

Used vertical stainless Steel tank. Dished top and bottom. Leg mounted.
