PET Partially Pulled Yarn (POY) Plant
Other Views - click image for larger view
PET Partially Pulled Yarn (POY) Plant PET Partially Pulled Yarn (POY) Plant PET Partially Pulled Yarn (POY) Plant PET Partially Pulled Yarn (POY) Plant PET Partially Pulled Yarn (POY) Plant PET Partially Pulled Yarn (POY) Plant

PET Partially Pulled Yarn (POY) Plant

Stock # 531
Capacity 60 TPD
Products PET Yarn

Overview

Used PET Partially Pulled Yarn (POY) plant including 3 direct spinning lines with totally 468 spinning points from Zimmer of Germany (Model: RICO - Fil. spinnerets diameter 100 mm and 85 mm) and 1 polyester chip spinning line from Barmag of Germany (spinnerets diameter 80 mm). It has a central polymer filter with 15 microns finesse. Each Zimmer line has 20 TPD capacity. Plant set up in a 3-story building, total space 1,000 m2. Power consumption 500 KW for the entire plant.

Major Equipment

POY direct spinning Zimmer lines
HTM vent condenser
HTM collecting tank
Preheat oven
Quench duct
Blower
Support frames and take-up machine
Static mixer
Thread take-up unit
Winder
HTM evaporator
Polymer heat exchanger
HTM cooler
Share
SPECIFICATIONS RESOURCES
Year Built
1998
Year Shut
2018
Capacity
60 TPD
