2200 HP Superior Boiler Works  Inc Firetube Boiler
Other Views - click image for larger view
2200 HP Superior Boiler Works  Inc Firetube Boiler 2200 HP Superior Boiler Works  Inc Firetube Boiler 2200 HP Superior Boiler Works  Inc Firetube Boiler 2200 HP Superior Boiler Works  Inc Firetube Boiler 2200 HP Superior Boiler Works  Inc Firetube Boiler 2200 HP Superior Boiler Works  Inc Firetube Boiler 2200 HP Superior Boiler Works  Inc Firetube Boiler

2200 hp superior boiler works inc firetube boiler

Stock # 19290
Capacity 2200 HP

Overview

Used 2200HP Apache 2-Pass Dryback Scotch Marine Package Boiler and Economizer. Manufactured by Superior Boiler. Model 8-X-11000-S150-GPCF-G. 2200HP (73,645 MBTU) steam OUT, Lo NOx natural gas fired 150 psig. Natural gas firing rate IN 92,400 cfh of 1000 BTU/cf. ASME Cleaver Brooks burner model LNXLG-924. Lo NOx < 30 ppm and 0.0364 lbs. per MMBTU. Includes controls and firing monitoring, gas train, forced draft blower, Kunkle safety valves 6x8" and 4x6" both set at 100 psig. Boiler dimensions are approx 151" w x 302" L x 153" tall. Cain economizer model RJR-166K26ALS. Stainless steel. Stack is Van-Packer Model DW 36" ID x 20'-9" long, ss304 insulated. Boiler Serial #16199. Boiler National Board# 16199. Built 2007. Weight empty 121,000 pounds.

Share
SPECIFICATIONS TERMS & CONDITIONS
Manufacturer
Superior Boiler Works, Inc
Model
8-X-11000-S150-GPCF-G
Material
Unknown
Capacity
2200 HP
