Used Brown, Boveri & Cie Process Equipment

Phoenix Equipment has a large inventory of used, unused, and reconditioned equipment from Brown, Boveri & Cie. Phoenix Equipment offers a wide selection of categories from Brown, Boveri & Cie. If you can't find the exact Brown, Boveri & Cie equipment you are looking for, contact us and we can help you find it.

Categories
Featured Equipment for Sale
113-mw-bbc-steam-turbine-generator
113 MW BBC Steam Turbine Generator
Stock# 12123 Capacity 113000 KW

113 MW (113,000 KW) Brown, Boveri & Cie. (BBC) Steam Turbine Generator. Type DK-722-2180. 3 stages: 1st adm. steam pressure 715PSIA @ 780F. 2nd adm. steam pressure 465PSIA @ 690F. 3rd adm. steam pressure 125PSIA @ 430F. Turning Gear motor speed 1800 rpm. Turbine speed 42 rpm. 105,000 sq ft Bechtel Construction Shell and Tube Surface Condenser with water box. Shell Carbon Steel. Tubes Inhibited Admiralty Bronze. Genset: Brown, Boveri& Cie Type (Air-Cooled) WZ18L-064LLT. Capacity 114,000 KVA. 2 poles @ 13.8Kv each. power factor 0.9. 4769 A. 3600 RPM. Exciter: Brushless. Brown, Boveri & Cie Type WBT74/508/30.
