Unused, never installed 80,000 kW ISO-rated gas turbine generator set manufactured by General Electric. The system includes one (1) GE PG7121EA combustion gas turbine, base rated at 62,480 kW and packaged as a power plant. The turbine operates at 60 Hz and is equipped with modulating inlet guide vanes (IGV), high-pressure brush packing in various locations, and a right-side exhaust exit system constructed with 409 stainless steel lagging and a carbon steel shell and diffusers. The combustion system uses water injection for NOx control, and the dual-fuel configuration supports crude oil and distillate fuels. Additional systems include lubrication and hydraulic units for the turbine and generator, a self-cleaning inlet filter, a water wash skid for maintenance, an AC motor start, and a rotor turning system. The control system is GE Mark VI with EX2100 brushless excitation. The generator is a GE Model 7A6, totally enclosed water-to-air cooled (TEWAC), rated at 102.7 MVA, 13.8 kV, 60 Hz, with a 0.8 power factor (wireless), and includes S/N 436X112. The turbine is enclosed in on-base lagging compartments and off-base turbine and accessory compartments with integrated freeze protection and ventilation systems. Fire protection is included in all compartments. Built in 2007, the equipment has been stored indoors in warehouse conditions since new and includes all related components, drawings, and manuals.
Accompanying the turbine is one (1) unused Deltak Heat Recovery Steam Generator (HRSG) specifically designed for use with the GE Frame 7EA turbine. The HRSG is duct-fired (Model DINO-3856) and was built in 2001. In unfired mode, it delivers high-pressure steam at 648 PSIG and 750°F with a flow rate of 333,258 lbs/hr, and low-pressure steam at 31 PSIG and 337°F at 51,142 lbs/hr. In duct-fired mode, the output increases to 954 PSIG and 753°F for high-pressure steam at 554,403 lbs/hr, and 72 PSIG and 358°F for low-pressure steam at 31,238 lbs/hr. The HRSG system includes high- and low-pressure steam drums, heat transformer modules, a deaerator system, duct burner system, isolation/vent/drain valves, HP/LP flow elements, field assembly fittings, ladders, and walkways. Items not included are emissions controls, boiler feed water pump, exhaust stack, and transition ducts. This unit has also been stored unused in warehouse conditions since manufacture.
