Caprolactam Plant - 50,000 TPY

Caprolactam Plant - 50,000 TPY

Stock # 233
Capacity 50,000 TPY
Products Caprolactam, Ammonium Sulfate

Overview

Used 50,000 TPY Caprolactam Plant. This plant used phenol as raw material to produce 50,000 TPY caprolactam and 140,000 ammonium sulfate. The plant was only operated for 4 years. All equipment is maintained well. Technical assistance for re-installation and start-up can be provided. This Caprolactam plant with production capacity 50.0 thousand tons per year (liquid and crystalline) and ammonium sulfate with project capacity 140.0 thousand tons per year. The finished product is the result of a process based on the reaction of oximation cyclohexanone with hydroxylamine sulfate, followed by isomerization (rearrangement Beckmann ) of obtained cyclohexanonoxim to Caprolactam.

Major Equipment

This 50,000 TPY Caprolactam Plant comes complete with the following equipment:
(6) Evaporation Columns
(10) Thin-Filmed Vaporizer
(16) Vaporizer
(4) Rectifiers
(10) Condensators
(11) Separators
(11) Vapro Ejectors
(10) Heat Exchangers
(4) Crystallizers
and Much More!
Share
SPECIFICATIONS RESOURCES
Year Built
1986
Year Shut
1990
Capacity
50,000 TPY
