Used Dresser Rand Process Equipment

Phoenix Equipment has a large inventory of used, unused, and reconditioned equipment from Dresser Rand. Phoenix Equipment offers a wide selection of categories from Dresser Rand. If you can't find the exact Dresser Rand equipment you are looking for, contact us and we can help you find it.

Categories
Featured Equipment for Sale
7-mw-dresser-rand-steam-turbine-generator
7 MW Dresser Rand Steam Turbine Generator
Stock# 12120 Capacity 7000 KW

Used 6.9 MW (6,957 KW) Dresser Rand Steam Turbine Generator, Straight Non-Condensing with Admission, with Flender reduction gearbox and GE (Gevisa) 4 pole, synchronous generator. Number of Stages – 7 Rateau. Serial # ET-184. Normal Power – 5908 KW. Inlet Steam Pressure – 850 psig; Inlet Steam Temperature – 905 F. Exhaust Pressure – 270 psig. Induction Pressure – 620 psig; Induction Temperature – 835 F. Frame – E 1SUISU4. Normal Speed – 6000 RPM. Max Cont. Speed – 6300 RPM. Trip Speed – 6600 RPM. 1st Critical Speed – 3300 RPM. 2nd Critical Speed – 7750 RPM. Gevisa Generator: KVA 8235, Voltage 13800, 60Hz, Ampere 345, Power Factor 0.85, KW 6999, Speed 1800. Built 2005.

15800-kw-dresser-rand-steam-turbine-generator
15800 KW Dresser Rand Steam Turbine Generator
Stock# 19716 Capacity 15800 KW

Unused 15MW Steam Turbine Generator. Manufactured by Dresser-Rand. Inlet Pressure 925PSIG@749F. Exhaust Pressure 235PSIG@477F. Trip Speed 3395 RPM. Max Cont RPM 3632. First Crit RPM 2550. Second Crit RPM 4900. Frame 1THB3HB2. Serial #D6397. Lufkin gearbox. Brush 18598kVA. Synchronous Generator PF: .85. 13.8kV, 60Hz, 4-pole. Brushless exciter. Rated current 778 A. Lube oil skid and control panel. includes (2) 5000 KVA Transformers 13.8 KV to 4160/2400 volts and (1) 2000 KVA Transformer 4160 to 480/277 volts.
