Used Energy Exchanger Process Equipment

Phoenix Equipment has a large inventory of used, unused, and reconditioned equipment from Energy Exchanger. Phoenix Equipment offers a wide selection of categories from Energy Exchanger. If you can't find the exact Energy Exchanger equipment you are looking for, contact us and we can help you find it.

Categories
Featured Equipment for Sale
318-sq-ft-energy-exchanger-carbon-steel-shell-tube-heat-exchanger
318 Sq Ft Energy Exchanger Carbon Steel Shell & Tube Heat Exchanger
Stock# 4917 Capacity 318 Sq Ft

Used vertical 318 Sq Ft Shell & Tube Heat Exchanger. CS Shell rated 515 PSI @ 550 deg F. CS Tubes rated 90 @ 370 deg F. 18" Shell x 10' L. (OAL - 13' 10"). (126) 1" OD Tubes x 10' L. Nozzles: Shell - 4" inlet, 2" outlet; Tubes - 6" inlet, 10" outlet. 1 Pass Shell, 1 Pass Tubes. Built by Energy Exchanger, 1981. S/N: x-1252, NB# 376. Weight: 4500 lbs. Previous Use: Ammonia Stripper Reboiler.

3579-sq-ft-energy-exchanger-stainless-steel-shell-tube-heat-exchanger
3579 Sq Ft Energy Exchanger Stainless Steel Shell & Tube Heat Exchanger
Stock# 7721 Capacity 3579 Sq Ft

Used 3579 Sq Ft Energy Exchanger Co. Vertical Stainless Steel Shell & Tube Heat Exchanger. 304L (Prtial) Shell rated 240 psig @ 530 F, 304 L Tubes rated 240 psig @ 350 F. (1586) 304L Tubes x 3/4" OD x 14 ga x 11' 6" Lg. Size 43 x 144 Type AEL. Lug Mounted. Serial #X-1167-A, National Board #296, Built 1980. Previous Use: Ethylene Oxide.

3654-5-sq-ft-energy-exchanger-carbon-steel-shell-tube-heat-exchanger
3654.5 Sq Ft Energy Exchanger Carbon Steel Shell & Tube Heat Exchanger
Stock# 7730 Capacity 3654.5 Sq Ft

Used 3654.5 Sq Ft Energy Exchanger Company Carbon Steel Vertical Shell & Tube Heat Exchanger. Shell rated 240 psig @ 550 F, Tubes rated 240 psig @ 420 F, Type AEL, Size 49 x 144. (1551) Tubes x 3/4" ID x 14 ga x 12' Lg. Shell Dimension: 4' 2 1/2" ID x 12' Lg. Lug Mounted, Serial #X-1168B, National Board #291, Built 1980. Previous Use: Ethylene Oxide.

3654-5-sq-ft-energy-exchanger-carbon-steel-shell-tube-heat-exchanger
3654.5 Sq Ft Energy Exchanger Carbon Steel Shell & Tube Heat Exchanger
Stock# 7731 Capacity 3654.5 Sq Ft

Used 3654.5 Sq Ft Energy Exchanger Company Carbon Steel Vertical Shell & Tube Heat Exchanger. Shell rated 240 psig @ 550 F, Tubes rated 240 psig @ 420 F, Type AEL, Size 49 x 144. (1551) Tubes x 3/4" ID x 14 ga x 12' Lg. Shell Dimension: 4' 2 1/2" ID x 12' Lg. Lug Mounted, Serial #X-1168A, National Board #287, Built 1980. Previous Use: Ethylene Oxide.

500-sq-ft-energy-exchanger-carbon-steel-shell-tube-heat-exchanger
500 Sq Ft Energy Exchanger Carbon Steel Shell & Tube Heat Exchanger
Stock# 18277 Capacity 500 Sq Ft

Used 500 sq. ft. vertical heat exchanger. Mfg. by Energy Exchanger Company in 2012. TUBES: 14' L x 0.75" Dia, 320 psig/FV at 385 F, tube holes 185, tube wall 0.083", carbon steel. SHELL: 1'4" Dia, carbon steel, 455 psig/FV at 515 F. S/N: X-7926. NB# 6052. Previous Service: Wastewater Ammonia Purifier Reboiler.
